169-101-10SPECIFICATIONSMetricCodeNo.169-101-10InchCodeNo.169-103-10Range(mm)Graduation(mm)MaximumpermissibleerrorJMPE(μm)Flatness(μm)Parallelism(μm)0-250.01±413Range(in)Graduation(in)0-10.001MaximumpermissibleerrorJMPE(in)±0.0002Flatness(in)Parallelism(in)0.000040.00015•StandardAccessories:Spanner(301336),1pc.SpecialPurposeMicrometersUnit:mm13.85.72561583.5Withoutrecessø14.3(ø0.44in)ø18(Spindledia.)ø6.350.40.425DIMENSIONS():inchmodel02-42PaperThicknessMicrometersSERIES169—Non-RotatingSpindleTypeMeasurementexample•Forpaperthicknessmeasurement.•Non-rotatingspindleeliminatestorqueonworkpiece.•Anvildiameter:ø14.3mm(withoutrecess)•EquippedwithRatchetStopforconstantmeasuringforce.(8.02±0.8N)
| <
|
> |
>>
