GaugeBlockComparatorsSPECIFICATIONSMetricRangeResolution0.5mm-100mm0.01µmAccuracyinnarrowrange(20°C)±(0.03+0.3L/1000)µm*L=Gaugeblocklength(mm)TypeLowergagingheadMeasuringforceContactpointMu-Checker0.4NCarbidecontactpointofradius5mmTypeUppergagingheadMeasuringforceContactpointMu-Checker0.8NCarbidecontactpointofradius20mmOperatingconditions20°C±1°CHumidity:58%RH±15%RH(Underlesstemperaturechange,andhotorcolddirectairflowshouldbeavoided.)*Notincludingtheuncertaintyofreferencegaugeblockandinuenceoftemperatures.01-34GaugeBlockCalibrationGaugeBlockComparatorGBCD-100ASERIES565—AutomaticComparatorwithDualGageHeadsGaugeblocksetforcomparatorcalibration(optional)Standardtype516-145-E2•Measuresthelengthofrectangulargaugeblocksinthesizerange0.5mmto100mm.ItautomaticallycomparesatestblockwithanappropriateReferencegaugeblock.Specialbridge-typeblock516-145-E2•Themeasurementresultisnotaffectedbyanywarpingofthinnergaugeblocksduetotheuseofupperandlowergageheads(dual-headsystem).•Measurementconguration:1cycleofautomaticcomparisonmeasurementwithaReferencegaugeblock.
| <
|
> |
>>
